Type:Serial Measurement Board
Model:3HAA3563-AMA/0
Series:ABB
Application Environment:Industrial
Operating Temperature Range:-25°C to +60°C
Data Transmission Protocol:RS-485
Maximum Data Rate:10 Mbit/s
Power Supply Voltage:DC 12V to 30V
Power Consumption:≤1W
Connector Type:M12
Number of Channels:8
Accuracy:+/-0.05% + 1LSB
Communication Distance:Up to 1500m
Engineered for seamless integration into complex industrial automation networks, the ABB 3HAA3563-AMA/0 Serial Measurement Board delivers unparalleled accuracy in data conversion. With its robust design and high-resolution capabilities, it ensures real-time monitoring and control, enhancing operational efficiency.
Featuring an advanced 16-bit ADC (Analog-to-Digital Converter), this board can handle a wide range of input signals, from voltage to current, making it suitable for various industrial applications. Its high sampling rate allows for precise tracking of rapid changes in process parameters, crucial for dynamic manufacturing processes.
Operated within a temperature range of -20°C to +60°C, the board is built to withstand challenging industrial environments, ensuring reliability and longevity. It supports RS-485 communication protocol at speeds up to 1 Mbps, enabling efficient data exchange with other devices in the network.
The ABB 3HAA3563-AMA/0 is designed for easy installation on DIN rails, allowing for quick deployment and minimizing downtime during setup or maintenance. Its low power consumption makes it an eco-friendly solution without compromising performance, reducing energy costs and environmental impact.
Backed by ABB’s commitment to quality and innovation, this Serial Measurement Board comes with comprehensive support and a long service life, ensuring that it remains a trusted choice for industrial automation needs.
