Operating Voltage (V):650V
Current Rating (A):122A
Switching Frequency (kHz):20 kHz
Thermal Resistance (°C/W):1.5°C/W
Insulation Resistance (MΩ):≥ 10^9
Operating Temperature Range (-°C to +°C):-40°C to +125°C
Package Size (mm):31.6 x 34.8 x 12.8
Cooling Method:Active Air Cooling
Control Interface:Digital Signal Input
Max Power Handling (W):7700W
The ABB 5SNA0600G650122 IGBT Module is a state-of-the-art component designed for integration into demanding industrial control applications. Its robust design ensures longevity and reliability in various operational environments.
Featuring advanced semiconductor technology, this IGBT module excels in handling high currents and voltages, making it ideal for applications requiring precise control over power delivery.
The module’s high insulation resistance and low gate drive requirements reduce the risk of malfunction and improve system stability. Its wide operating temperature range (-40°C to +175°C) ensures reliable performance even in extreme conditions.
For ease of installation and maintenance, the ABB 5SNA0600G650122 comes equipped with an efficient air cooling system. This minimizes the need for complex cooling solutions, simplifying the overall system architecture.
Engineered with precision and innovation, this IGBT module from ABB is not only a testament to technological advancement but also a reliable partner in enhancing the efficiency and reliability of industrial control systems.
