Operating Temperature Range:-40°C to +125°C
Peak Current Rating:2000 A
Insulation Class:F
Maximum DC Voltage:1600 V
Module Size:170 mm x 140 mm
Cooling Method:Air Cooled
The ABB AGDR-71C IGBT module is engineered with state-of-the-art technology to deliver exceptional performance in industrial control systems, renewable energy applications, and electric drives. Its robust design ensures reliability and longevity under various operating conditions.
Featuring a compact TO-247 package, this module offers a balance between size and heat dissipation efficiency, making it suitable for space-constrained environments without compromising on cooling performance.
With a high insulation resistance, the AGDR-71C module is designed to withstand harsh industrial environments, ensuring reliable operation even in challenging conditions. This makes it ideal for use in demanding applications such as motor control, HVAC systems, and power supply units.
The ABB AGDR-71C IGBT module supports a wide range of switching frequencies, allowing it to adapt to different system requirements and enhance overall system efficiency. It is capable of handling high currents efficiently, making it suitable for applications requiring significant power transfer.
Certified to IEC 60071-2 and IEC 60071-4 standards, the AGDR-71C module meets the stringent safety and performance criteria set by international regulatory bodies. This ensures that users can trust the product to perform reliably and safely in their systems.
