ABB HESG447220R4 Monitoring Module PCB Circuit Board

Brand:ABB

Model Number:HESG447220R4

Series:Industrial Monitoring

Product Type:PCB Circuit Board

Dimensions:W x L x H (inches): 6.4 x 10.6 x 1.2

Weight:Approximately 1.2 lbs

Operating Temperature Range:-20°C to +70°C

Storage Temperature Range:-40°C to +85°C

Material:High-grade FR4 epoxy resin

Input Voltage:DC 24V

Communication Interface:RS-485

Power Consumption:Maximum 2W

    The ABB HESG447220R4 Monitoring Module PCB Circuit Board is engineered with precision and robustness in mind, providing reliable monitoring solutions for complex industrial applications. Its high-grade copper-clad laminate ensures durability and exceptional electrical performance.

    Featuring an optimal size of 150mm x 100mm x 5mm, the module is designed for efficient space utilization in various industrial setups. It supports a wide voltage range from 100V to 240V AC, ensuring compatibility with diverse power sources.

    Operable within a temperature range of -20°C to +70°C, this PCB module is built to withstand harsh industrial environments, guaranteeing consistent performance throughout extreme conditions. Its compact design, coupled with a low power consumption of 10W, makes it energy-efficient and suitable for continuous operation without significant heat generation.

    Equipped with a robust RS-485 communication interface, the ABB HESG447220R4 Monitoring Module facilitates seamless data transfer between the board and other components, enhancing system reliability and reducing downtime. This feature is crucial for maintaining real-time monitoring and control over industrial processes.

    The module complies with international safety and quality standards, including CE, UL, and ISO 9001 certifications. These endorsements affirm its adherence to stringent safety protocols, ensuring that users receive a product that meets the highest industry standards for quality and reliability.
