Model Number:1768-CNBR
Series:CompactLogix L4x
Module Type:Motion Control
Processor Speed:20 MHz
Memory Capacity:512 KB RAM, 512 KB Flash ROM
Operating Temperature Range:-20°C to 60°C
Power Consumption:50 VA
Communication Protocols:[“EtherNet/IP”,”DeviceNet”]
Mounting Options:[“Panel”,”DIN Rail”]
Dimensions (WxHxD):146 x 96 x 100 mm
Weight:0.6 kg
The Allen-Bradley 1768-CNBR CompactLogix L4x Control Module is designed for seamless integration into a wide range of industrial environments. It boasts a compact yet robust design, making it suitable for space-constrained applications. Its modular architecture allows for flexible configuration, accommodating diverse control needs without compromising on performance.
Equipped with advanced communication protocols such as Modbus TCP/IP, DeviceNet, and EtherNet/IP, this module ensures seamless connectivity with other devices and systems within the production line, enhancing efficiency and productivity. The integrated memory provides ample space for storing user programs and data, ensuring smooth operation even under demanding conditions.
The 1768-CNBR is engineered to withstand harsh industrial environments. It operates within a temperature range from -40°C to 70°C (-40°F to 158°F), ensuring reliability across various geographical locations. Moreover, its wide power supply compatibility (12 to 30 VDC) makes it adaptable to different power sources commonly found in industrial settings.
With its high processing speed of up to 100 K instructions per second, the module delivers swift response times and efficient execution of control tasks, optimizing system performance. Additionally, the support for up to 16 I/O points allows for precise control over actuators, sensors, and other devices, making it an indispensable component in modern automation systems.
The Allen-Bradley 1768-CNBR CompactLogix L4x Control Module is designed with user-friendliness in mind. It features intuitive programming through ladder logic, simplifying setup and maintenance tasks. Its compatibility with Allen-Bradley’s Studio 5000 software further enhances its usability, providing a comprehensive toolset for designing, debugging, and commissioning control systems.
