Operating Voltage:12 – 48V DC
Current Consumption:≤ 15mA
Sampling Frequency:Up to 100 kHz
Counting Channels:4
Counting Modes:Up, Down, Up/Down
Range:-32767 to +32767 counts
Counter Accuracy:±1 part in 4 million
Resolution:0.001 count
Communication Interface:ControlLogix Ethernet
Temperature Range:-40°C to 85°C
Enclosure Rating:IP20
Mounting Type:Panel
Connection Type:MODBUS TCP/IP
Engineered for demanding industrial environments, the Allen-Bradley 1756-HSC ControlLogix High Speed Counter Module provides exceptional accuracy in high-speed counting and timing tasks.
This module is ideal for applications requiring precise measurement and control, such as machine tool synchronization, robotic cycle timing, and process monitoring systems.
Featuring a compact design and rugged construction, it ensures reliable performance under extreme conditions, enhancing system uptime and reducing maintenance needs.
Integrated with the ControlLogix platform, it seamlessly communicates via ControlNet or DeviceNet, offering a seamless integration with other Allen-Bradley components for enhanced automation capabilities.
The 1756-HSC is equipped with advanced error detection features, including under-range and over-range protection, ensuring robust operation and minimizing downtime.
