Operating Voltage:24V DC
Rated Current:2A max
Number of Outputs:16 channels
Output Configuration:NPN/PNP
Operating Temperature Range:-25°C to +70°C
Protection Class:IP20
Communication Interface:ControlNet
Dimensions:9.5 x 5.2 x 1.4 inches
The Allen-Bradley 1756-OA16 ControlLogix Output Module is designed for high-performance control in demanding industrial environments. This module ensures reliable and consistent output performance, making it ideal for complex automation tasks where precision is critical.
Featuring solid-state technology, the 1756-OA16 provides long-lasting durability and reduced maintenance compared to traditional relay outputs. It supports 16 individual channels, each capable of delivering up to 3.3 A at 24 VDC, ensuring robust control capabilities.
Equipped with 2 Form C relay contacts, the module ensures safe and secure switching operations, providing a reliable connection for various industrial equipment. Its advanced isolation feature maintains system integrity by preventing electrical interference between the module and its environment.
With support for ControlNet communication, this output module seamlessly integrates into existing industrial automation systems, facilitating efficient data exchange and process control. Its compatibility with ControlLogix technology ensures seamless integration with other Allen-Bradley products, enhancing overall system performance.
Designed for ease of installation and operation, the 1756-OA16 is suitable for panel mounting. It operates within a wide temperature range (-40°C to +70°C), making it suitable for harsh industrial conditions. The IP55 environmental rating ensures protection against dust and water ingress, safeguarding the module’s performance in outdoor or dusty environments.
