Number of Channels:32
Output Voltage Range:5 to 50 VDC
On-State Voltage Drop:1.2 V
Off-State Output Leakage:1 MA
Load Capacity:1 MA
Continuous Current per Output:0.25 A at 60 °C
Continuous Current per Module:8 A at 60 °C
Isolation Voltage:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Processor Type:SLC 500
Enclosure Type:Open Type
Mounting:Chassis
Temperature Rating:0 to 60 °C
Environmental Conditions:5 to 95% non-condensing relative humidity
Experience unparalleled control and efficiency with the Allen Bradley AB 1746-OB32E SLC 500 DC Output Module, designed for industrial automation applications. This high-performance module is equipped with 32 channels, providing robust output capabilities to meet the demands of even the most complex systems.
Featuring a backplane current rating of 190 mA, this module ensures stable operation under varying conditions, while its continuous current per output at 60°C is rated at 0.25 A, ensuring reliable performance. With an off-state output leakage of 1 mA, it minimizes power loss, optimizing system efficiency.
The Allen Bradley AB 1746-OB32E boasts an isolation level of 500 VDC for communication circuits and 1500 VAC for the backplane, ensuring isolation between the module and the rest of the system, enhancing safety and reliability. Its open type enclosure and chassis mounting design facilitate easy installation and maintenance.
Equipped with a temperature rating of 0 – 60°C, this module is designed to operate in a wide range of industrial environments, from cold to warm climates. It supports non-condensing relative humidity levels up to 95%, ensuring durability in humid conditions.
For added protection against mechanical shocks, the Allen Bradley AB 1746-OB32E withstands 30 G shock, making it suitable for applications where equipment may be subjected to vibrations or impacts. This module is a testament to Allen Bradley‘s commitment to delivering high-quality, reliable automation solutions.
