Asahi Keiki AP-102-13-11 Micro DC Signal Isolation Transmitter

Input Voltage Range:12V to 24V DC

Output Voltage Range:0V to 10V DC

Operating Temperature:-20°C to +85°C

Isolation Voltage:1000V AC

Accuracy:+/- 0.1% F.S.

Current Consumption:Typically 1mA @ 24VDC

    The ASAHI KEIKI AP-102-13-11 Micro DC Signal Isolation Transmitter is a cutting-edge solution for industrial control systems, offering unparalleled accuracy and reliability in signal conversion and isolation. Its compact terminal type design ensures seamless integration into various automation setups, while its robust construction withstands harsh industrial environments.

    With an impressive signal input range from -10V to +10V DC, this transmitter can handle a wide variety of industrial signals, making it suitable for diverse applications. The output range of 0V to 10V DC ensures compatibility with most digital displays and control systems.

    The 2500Vrms isolation voltage guarantees excellent electrical safety and prevents cross-contamination between different circuits, crucial for maintaining system integrity in complex industrial settings.

    Featuring two relay outputs, the transmitter provides additional functionality for control applications, enabling the activation of external devices based on the input signal. The 3A/250VAC relay contact rating ensures reliable switching capabilities.

    The integrated 4-20mA communication interface supports advanced data transmission, facilitating seamless communication within industrial networks. The transmitter operates efficiently over a broad temperature range (-20°C to +85°C), ensuring reliable performance under extreme conditions.

    Equipped with a protection class of IP20, the ASAHI KEIKI AP-102-13-11 is protected against solid foreign objects but does not provide dust tight protection, making it suitable for industrial environments with moderate dust levels.
