GE 750-P5-G5-S5-HI-A20-R-E Relay – Advanced Industrial Control Solution

Communication Baud Rate:300 to 19200 baud

Operating Voltage:220 (V)

Output Frequency:50 (kHz)

Certification:Certified Product

Series:SR750-P5-G5-S5-HI-A20-RT Series

Relay Dimensions:Approx. 18cm W x 16.5cm L x 21.5cm H

Material Coding:SR750-P5-G5-S5-HI-A20-RT

Insulation Voltage:300 V

Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01

Relay Type:Active

Communications Protocol:Modbus RTU or DNP 3.0

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays

Operating Environment:Humidity up to 90% non condensing

Environmental Protection Degree:II

    The GE 750-P5-G5-S5-HI-A20-R-E-H Relay is a high-performance device designed for distribution feeder control and protection in industrial environments. It boasts advanced communication capabilities, ensuring reliable data exchange with other systems.

    With a robust frequency range of 25 to 60 Hz, this relay is capable of operating under various industrial conditions, providing a stable and consistent performance. The insulation voltage of 300 V guarantees enhanced safety, making it suitable for environments with high electrical demands.

    Featuring a wide overvoltage pickup level from 0 to 1.25 × VT in steps of 0.01, the relay offers superior protection against overvoltages, safeguarding connected devices from potential damage. Its versatile waveform capture channels allow for detailed monitoring of currents, voltages, and logic states, enhancing operational efficiency.

    This relay is compatible with a standard 19-inch panel, offering flexible installation options for various industrial setups. The compact dimensions (approx. 18cm W, 16.5cm L, 21.5cm H) make it easy to integrate into existing systems without compromising space.

    The GE 750-P5-G5-S5-HI-A20-R-E-H Relay withstands high humidity levels up to 90% non-condensing, ensuring reliable operation even in demanding environmental conditions. Additionally, its pollution degree rating of II indicates it is suitable for harsh industrial environments with potential dust or chemical exposure.
