Brand:General Electric
Model:DS200CTBAG1ADD
Type:Terminal Board
Series:Mark V
Weight:0.45 Kg
Dimensions:W x H x D: 200mm x 150mm x 100mm
Connectors:[“COREBUS”,”IONET”,”ARCNET”]
Operating Temperature Range:-40°C to +70°C
Power Supply:DC 24V
Communication Interface:RS-232, 9-pin d-shell
Number of Channels:Multiple
The GE DS200CTBAG1ADD Terminal Board is designed to enhance the performance of the GE Speedtronic MKV Gas Turbine control system. This advanced module is strategically positioned within the C-core of the system to ensure seamless integration and optimal operation.
Equipped with multiple connectors including COREBUS (JAI and JAJ), it supports diverse communication protocols, ensuring reliable data transmission between various system components.
Featuring two double-stack terminal strips with multiple connectors on each, the DS200CTBAG1ADD allows for flexible and scalable connections, accommodating a wide range of signal types from Ma.Input, Ma.Output, to serial ports for diagnostics.
The presence of a 9-pin male serial connector enables direct interface with external devices, enhancing system monitoring and control capabilities. Moreover, the inclusion of two vertical pin cable and header connectors ensures compatibility with a variety of peripheral equipment.
Engineered for robustness and durability, the DS200CTBAG1ADD Terminal Board withstands extreme environmental conditions, making it a reliable choice for harsh industrial environments. It is meticulously crafted to deliver exceptional performance, ensuring continuous and efficient operation of the gas turbine control system.
