Manufacturer:Hybricon
Model:078-453
Module Type:Digital Input Module
Input Channels:16
Voltage Range:12-48V DC
Power Consumption:2W
Operating Temperature:-25°C to +70°C
Storage Temperature:-40°C to +85°C
Humidity Range:5% to 95% non-condensing
Communication Protocol:Modbus RTU
Dimensions:120mm x 80mm x 40mm
Weight:0.3kg
This communication module is built with the latest technology to ensure seamless integration with existing systems. Its full software configuration capability eliminates the need for manual module jumpers, enhancing ease of use. With six hardware analog-to-digital filter frequencies, each channel can independently select its own filtering frequency, ensuring rapid data acquisition and automatic calibration. The module supports multiple input types, including RTD short circuit detection, user-defined range scaling, and high/low alarm detection, with detailed fault reporting and diagnostic capabilities. The HYBRICON 078-453 is designed for universal application, capable of replacing third-party modules like thermocouples, strain gauges, RTDs, voltage, and current modules. It offers superior performance with its built-in 10M/100M switchable Ethernet ports, fully compliant with TCP/IP standards for easy network integration. The Genius network’s unique high immunity to interference allows for long-distance communication using shielded twisted pair cables up to 2.3 km, or fiber optics up to 15 km, without the need for repeaters or active terminators. This ensures reliable and stable operation even in harsh industrial environments.
