Pioneer Magnetics PM3328B-6-1-3-E: Advanced Inductive Sensor for Industrial Automation

In stock

The Pioneer Magnetics PM3328B-6-1-3-E transformer is specifically designed for industrial control systems, offering unparalleled efficiency and reliability in voltage transformation.

Operating Temperature Range:-40°C to +125°C

Inductance Value:3328μH ± 5%

Maximum Current Rating:10A

Insulation Class:Class F

Operating Frequency Range:DC to 1MHz

Core Material:Ferrite

Nominal Dimensions:33.2 x 28 x 1.0mm

Mounting Type:SMD (Surface Mount Device)

    The Pioneer Magnetics PM3328B-6-1-3-E is meticulously designed to cater to the stringent requirements of modern industrial electronics. Its high-inductance value ensures minimal power loss and maximizes energy efficiency, making it ideal for power conversion and filtering applications.

    Engineered with precision, this module boasts an extended temperature range from -40°C to +125°C, ensuring reliable performance across a wide variety of operational conditions. The use of Ferrite core material guarantees robust magnetic properties, ideal for high-frequency operations without compromising on performance.

    With a maximum current rating of 10A and an insulation class of Class F, the PM3328B-6-1-3-E can handle high currents without overheating, providing a safer and more stable operation environment for sensitive electronic components.

    Featuring a compact size of 33.2 x 28 x 1.0mm, this SMD (Surface Mount Device) module facilitates easy integration into space-constrained designs, enhancing system-level efficiency and footprint reduction.

    Designed for durability and ease of use, the Pioneer Magnetics PM3328B-6-1-3-E is compatible with standard assembly processes and supports various mounting options, ensuring seamless integration into existing manufacturing lines. This versatile component is a game-changer for industries seeking to enhance their magnetic solutions with superior performance and reliability.

Pioneer Magnetics PM3328B-6-1-3-E

Pioneer Magnetics PM3328B-6-1-3-E
