Dimensions:275.86mm x 206.86mm x 59.75mm
Display Size:10.1” wide
Enclosure Rating:NEMA 4 with screw fasteners, Front IP65, Rear IP20
Features:RTC Battery and USB type A
Input Voltage:24Vdc
Operating Temperature:0 to 50 °C
Power Consumption:8.2 W
Resolution:800 x 480 pixels (WVGA)
The PRO-FACE PFXGE4501WAD is part of the Pro-face GC4000 Series and belongs to the HMI family. Its 10.1-inch wide display provides an expansive viewing area, making it ideal for monitoring and controlling complex industrial processes. The display’s 800 x 480 pixel resolution ensures clear visibility, even in bright conditions.
This HMI features a robust NEMA 4 enclosure rating, ensuring it can withstand harsh industrial environments. The front IP65 and rear IP20 ratings further enhance its durability and reliability.
Equipped with an RTC battery, the PFXGE4501WAD maintains accurate timekeeping even during power outages. The USB type A port allows for easy data transfer and storage.
With a power consumption of only 8.2 W, this HMI is energy-efficient without compromising performance. It operates within a temperature range of 0 to 50 °C, making it suitable for a wide range of applications.
