Product Type:Module
Product ID:TSXASZ401
Manufacturer Type Designation:Schneider
Specification Range:Modicon TSX Micro automation platform
Component Type:Analog output module
Number of Channels:4
Analog Output Type:0…10 V, +/- 10 V
Current Consumption:90 mA
Power Supply Voltage:DC 5 V
Product Weight:0.44 lb (US) / 0.2 kg
Ambient Temperature:Maximum of +50°C
Overall Dimensions:Width 239mm, Length 90mm, Depth 194mm
Control Panel:Yes
Drive Type:Variable Speed
Communication Type:FC Protocol, Modbus RTU
Filter:Included
Function:Motor Control
Special Features:Excellent Reliability, Integrated Braking Chopper, User Friendly
Standards Met:ISO 14001, RoHS, WEEE
IP Rating:IP20
Mounting Type:Panel Mount
The Schneider TSXASZ401 is a high-performance, 4-channel analog output module designed for industrial control applications requiring precision and reliability. Its modular design ensures seamless integration into existing control systems, offering unrivaled scalability and flexibility.
Each channel supports a wide voltage range, from 0…10 V and +/- 10 V, enabling versatile application across various industries. The low current consumption of 90 mA ensures efficient power usage, making it an economical choice for long-term operation.
With an ambient temperature maximum of +50°C, this module operates reliably in demanding environments, ensuring continuous performance even under harsh conditions. Its compact size (239mm x 90mm x 194mm) allows for efficient space utilization on control panels.
Equipped with a user-friendly control panel and field bus communication capabilities through FC Protocol and Modbus RTU, the Schneider TSXASZ401 simplifies integration with other systems and devices, enhancing system interoperability and efficiency.
This module is built to meet stringent international standards, including ISO 14001 for environmental management, RoHS for hazardous substance restrictions, and WEEE for waste electrical and electronic equipment. Its IP20 rating ensures protection against dust and splashes, further enhancing its robustness in industrial settings.
