Siemens 2098-DSD-020X | Advanced Process Control Module

In stock

The Allen-Bradley 2098-DSD-020X is a high-performance digital servo drive designed for precise motion control in industrial automation applications. It seamlessly integrates with servo motors, offering superior speed regulation and precise positioning capabilities.

Operating Temperature Range:-40°C to 70°C (-40°F to 158°F)

Relative Humidity:5% to 95% non-condensing

Input Voltage:120-240V AC, 1-Phase

Nominal Current:18A RMS

Bus Capacitance:1880 μF

Bus Overvoltage Protection:400V DC

Energy Absorption Capability:51 Joules

Output Power:2kW

Output Current:Continuous 10A, Peak 30A

Maximum Power Dissipation:50W

PID Controller Update Rate:250 μs

Feedback Type:Optically Isolated Digital Inputs and Outputs

Auxiliary Supply Voltage:5V DC

    The Allen-Bradley 2098-DSD-020X boasts an ultra-compact design weighing just 2.1 kg (4.6 lbs) with dimensions of 98.1mm x 32.77mm x 65.02mm, making it an ideal choice for space-constrained environments.

    Equipped with an advanced Proportional+Integral+Derivative (PID) velocity regulator with a 250 μs update rate, this servo drive ensures smooth and accurate motion control, even in demanding applications.

    Featuring 8 optically isolated digital inputs and 4 N.O. relay outputs rated for 30V DC max voltage and 1A max current, the 2098-DSD-020X provides versatile connectivity options for various control scenarios.

    The 2098-DSD-020X supports feedback position data from a variety of encoders including Allen-Bradley sine/cosine and incremental models, ensuring precise positioning control.

    With its robust construction and comprehensive feature set, the Allen-Bradley 2098-DSD-020X is engineered to deliver unparalleled reliability and performance, making it a preferred choice for manufacturers seeking to optimize their production lines.

2098-DSD-020X   2098DSD020X
