Power Rating (kW):0.4
Voltage (VAC):200
Servomotor Type:Flat; Pancake
Rated Speed (RPM):3,000
Max Speed (RPM):5,000
Mounting Type:Flange Mount
Encoder Type:Incremental Encoder
Bit Resolution:13 BIT
Constant Torque (Nm):1.27
Peak Torque (Nm):3.82
Peak Torque (in-oz):542
Constant Torque (in-oz):180
Constant Torque (in-lb):11.24
Peak Torque (in-lb):33.8
Brake:Yes
IP Rating:IP67
Approvals:UL; CE; cUL Recognized
Model Number:SGMAV-A5ANA-YR23
The Yaskawa SGMAV-A5ANA-YR23 servo motor is a cornerstone of precision motion control in industrial automation, featuring a compact, flat design that maximizes space utilization on machinery.
With a rated speed of 3,000 RPM and a maximum speed reaching up to 5,000 RPM, this motor is engineered for applications demanding high-speed, accurate positioning.
Equipped with an incremental encoder, it offers precise feedback for enhanced control and repeatability in manufacturing processes.
Capable of delivering a constant torque of 1.5 Nm and a peak torque of 4.5 Nm, the motor ensures robust performance even under varying loads.
The inclusion of a brake system ensures smooth operation and safety, preventing unwanted movement when the power is off.
Certified to IP67 standards, this motor is protected against dust ingress and can withstand water jets from any direction, making it suitable for harsh industrial environments.
Compliant with international safety standards including UL, CE, and cUL Recognized, it guarantees reliability and safety in global applications.
