Yokogawa AAM51 Current Voltage Output Module

Output Signal 1:4 to 20 mA DC

Output Signal 2:0 to 10 V DC

Output Resistance 1:1 Ohm or less

Output Resistance 2:500k Ohm or more

Allowable Load Resistance:10k Ohm or more

Output Range 1:0.3V DC to 10.3V DC

Output Range 2:1.0mA DC to 21.5mA DC

Output Voltage Limit:25.5V DC or less

Output Current Limit:60 mA DC or less

Output Open:N/A

Operating Voltage:220V AC/DC

Certified Product:Yokogawa AAM51

Model:AAM51

    The Yokogawa AAM51 Current Voltage Output Module is engineered with precision and reliability to meet the demanding requirements of modern industrial control systems. This module is specifically designed to provide accurate and stable current and voltage outputs, ensuring optimal performance in various operational scenarios.

    Featuring a compact and robust design, the AAM51 is compatible with CENTUM CS 3000 and CENTUM CS 1000 systems, enhancing its versatility across different applications. It offers high-quality signal transmission, making it ideal for use in critical processes where accuracy and dependability are paramount.

    This module comes equipped with advanced features such as customizable settings and open circuit protection, which safeguards against potential damage caused by open circuits during operation. These protective measures contribute to increased system uptime and efficiency, minimizing downtime and maintenance costs.

    In terms of technical specifications, the AAM51 boasts an output signal range from 0 to 10 V DC and 4 to 20 mA DC, with precise control over output resistance, allowing for flexible integration into diverse control systems. Its wide allowable load resistance ensures compatibility with a broad spectrum of load capacities, ensuring reliable operation under varied conditions.

    Moreover, the AAM51’s output range extends from -0.3 to 10.3 V DC for voltage outputs and 1.0 to 21.5 mA DC for current outputs, coupled with limits on voltage and current output, ensuring safety and preventing potential overloads. This combination of features makes the AAM51 a valuable addition to any industrial control setup, aiming for enhanced performance, reliability, and efficiency.
